Introduction
Mechanical clocks often develop unusual noises as they age. A growling, rubbing, or grinding sound usually indicates friction in the train, worn bushings, or escapement issues. This guide explains how to identify the source of unwanted noise, how to distinguish normal ticking from problematic sounds, and how to restore quiet, smooth operation.
Understanding Clock Noise
Normal ticking
A healthy clock produces a steady, even tick‑tock sound. Variations indicate beat or escapement issues.
Growling or rumbling
Often caused by friction in the gear train, worn pivots, or dry bushings.
Rubbing or scraping
Indicates a wheel rubbing a plate, a bent arbor, or a misaligned pivot hole.
Fluttering
A rapid, buzzing sound caused by shallow escapement lock or excessive power reaching the escape wheel.
Hammer or chime noise
Loose hammer tails or chime rods can create additional vibration or rattling.
Common Causes of Growling Noises
Dry pivots
Lack of lubrication increases friction and produces a low growling sound.
Worn bushings
Oval pivot holes cause wheels to lean, rubbing the plates or other wheels.
Bent arbors
A bent arbor causes uneven rotation and intermittent scraping.
Escape wheel wear
Worn or bent escape wheel teeth cause irregular ticking and grinding sounds.
Pendulum interference
If the pendulum rod or spring rubs the case, it creates rhythmic noise.
Diagnosing the Source of the Noise
Listen closely to the plates
Place your ear near the movement to determine whether the noise comes from the train, escapement, or pendulum.
Check pivot wear
Move each wheel gently side‑to‑side. Excess play indicates worn bushings.
Inspect the escape wheel
Look for bent teeth, uneven spacing, or rough tips that cause irregular ticking.
Check for rubbing wheels
Shine a light between the plates to see if any wheel is contacting the plate or another wheel.
Observe pendulum clearance
Ensure the pendulum rod and spring do not touch the crutch, back plate, or case.
Correcting the Problem
Apply proper lubrication
Use clock‑grade oil sparingly on pivots. Over‑oiling attracts dirt and increases friction.
Install bushings where needed
Worn pivot holes must be bushed to restore proper depthing and reduce noise.
Straighten bent arbors
Correcting arbor alignment eliminates scraping and uneven rotation.
Dress or replace the escape wheel
Repair bent teeth or replace the wheel if wear is severe.
Adjust pendulum alignment
Ensure the pendulum rod and spring hang straight and do not rub the case.
Troubleshooting Flowcharts
If the clock makes a growling noise
Check pivots → Check bushings → Check escape wheel → Check arbor alignment → Oil lightly
If the noise is rhythmic
Check pendulum rod → Check suspension spring → Check crutch → Check case clearance
If the noise comes from the escapement
Check lock → Check drop → Check escape wheel teeth → Check verge alignment
If the noise changes with beat adjustment
Check crutch → Check pendulum → Check suspension → Check verge depth
If the noise persists after oiling
Inspect bushings → Check wheel depthing → Check bent pivots → Clean movement
Common Mistakes to Avoid
Over‑oiling the movement
Too much oil causes drag and attracts dirt.
Ignoring worn bushings
Worn pivot holes are a major cause of noise and power loss.
Forcing the escape wheel
Escape wheel teeth bend easily and must be handled carefully.
Misdiagnosing pendulum noise
Pendulum rubbing can mimic train noise. Always check clearance.
Skipping cleaning
Dirt and dried oil amplify friction and noise.
Checklist for Final Verification
• Pivots properly lubricated
• Escape wheel teeth inspected
• Pendulum rod and spring clear of obstructions
• No rubbing between wheels and plates
• Movement runs quietly and evenly
• Beat adjusted for smooth operation
FAQs
Why does my clock make a growling sound?
Usually due to friction from dry pivots, worn bushings, or escape wheel wear.
Can oil fix the noise?
Only if the issue is dry pivots. Worn bushings require repair.
Can the pendulum cause noise?
Yes. A rubbing pendulum rod or spring creates rhythmic sounds.
Why does the escape wheel make noise?
Bent or worn teeth cause irregular ticking or grinding.
Is noise normal in old clocks?
Some ticking is normal, but growling or scraping indicates a problem.
