Restoring a French silk suspension movement requires a delicate touch and a deep understanding of old French measurements. Experts suggest that when a clock runs significantly fast—sometimes gaining 8 to 10 minutes per hour—it is often due to an incorrect pendulum length or an improperly adjusted crutch that "drives" the pendulum rather than allowing it to swing freely. Ensuring every component from the silk loop to the leader block is correctly configured is essential for achieving reliable timekeeping.
Diagnostic Checklist: Silk Suspension & Pendulum
- 1. Crutch and Leader Clearance:
- Repairers suggest that the crutch loop must never grip the pendulum leader block firmly. There should be a minimal clearance—approximately .001" to .002" (the thickness of a piece of paper)—so the crutch "taps" the leader on each side of the swing.
- 2. Silk Loop Geometry:
- Restorers recommend keeping the silk loop short, ideally around 1 cm. A loop that is too long or "floppy" can lead to inconsistent power delivery and erratic timing.
- 3. Proper Measurement Points:
- Experts suggest that the calculated pendulum length is measured from the flex point where the silk passes through the post down to the center of mass of the entire bob and leader assembly.
Understanding the 7 5 and 7 3 Stamps
French clocks often have numbers stamped on the back plate, such as "7 5" or "7 3," which represent old French measures in Pouces and Lignes. A "7 5" stamp indicates a required pendulum length of approximately 7.904 US inches, while a "7 3" stamp requires about 7.727 inches. Restorers suggest that if the correct pendulum for the movement hits the bottom of your clock case, the clock may be missing an original marble or wooden pedestal.
The "square peg in a square hole" design found on many French leaders is critical for stability. Because the silk thread is so flexible, experts suggest this design prevents the pendulum from rotating or wobbling during its oscillation, which would otherwise ruin the clock's accuracy. If you are using a replacement leader, you may need to file and polish the block so it fits the rectangular crutch opening with the necessary precision.
Frequently Asked Questions
1. Why does my clock run fast even after I lengthened the pendulum? Experts suggest checking the escapement depth. If the verge is too shallow, the escape wheel teeth may land on the impulse faces instead of the dead faces, causing it to act like a recoil escapement and run fast.
2. Will a heavier bob slow down my clock? Repairers suggest that the weight of the bob has very little effect on the rate compared to the length. However, if a heavier bob is also larger, it may actually raise the center of oscillation and make the clock run faster.
3. What happens if the crutch is too tight on the leader? Restorers suggest this "tight" condition causes the pendulum to be more or less "driven" rather than swinging freely, which makes it extremely difficult to regulate and often leads to the clock running too fast.
4. How can I determine the correct length if there is no stamp? Experts recommend "counting the train" (counting the teeth on the wheels) and using a pendulum length formula to calculate the exact beats per hour required.
5. Should I oil the crutch and leader contact point? Yes, restorers recommend that the point of contact should be polished smooth and lightly oiled to minimize friction.
