Introduction
The Seth Thomas 89 movement is known for reliability, but the upper train—especially the regulating components—can develop wear that causes erratic running, weak motion, or intermittent stoppage. When the regulating section misbehaves, the cause is usually found in tooth wear, pivot friction, or loss of power in the high‑speed wheels. This guide explains how to diagnose these issues and restore proper operation.
Where Problems Occur in the Upper Train
High‑speed wheel pivots
These pivots wear quickly and develop oval holes that reduce power.
Tooth wear or burrs
Even slight burrs on the high‑speed wheels cause hesitation and uneven motion.
Regulating‑component friction
Any drag in this area reduces amplitude and causes erratic timing.
Power‑train contamination
Dirt or dried lubricant increases friction and accelerates wear.
Plate wear
Older plates may develop oval holes that disrupt depthing and power flow.
Common Symptoms
Weak pendulum motion
Indicates power loss in the upper train.
Clock stops randomly
Often caused by intermittent friction or worn pivot holes.
Uneven motion
Wear causes inconsistent impulses and unstable timing.
Tick‑tock not even
Friction or wear disrupts the regulating action.
Sensitive to case tilt
Worn pivots reduce tolerance for misalignment.
How to Diagnose the Issue
Check pivot holes
Look for ovaling, dark residue, or excessive side‑shake.
Inspect tooth condition
Check for burrs, bent teeth, or contamination.
Test train freedom
Spin the wheels gently—any hesitation indicates friction.
Observe pendulum amplitude
Weak amplitude points to upper‑train drag.
Check for contamination
Dirt or dried lubricant increases friction and accelerates wear.
Correcting the Problem
Step 1: Clean the movement
Remove old residue and contamination that increase friction.
Step 2: Bush worn pivot holes
Oval holes must be corrected to restore proper depthing and power.
Step 3: Polish pivots
Smooth pivots reduce friction and improve power transfer.
Step 4: Dress worn teeth
Remove burrs and correct minor tooth damage to restore smooth rotation.
Step 5: Verify pendulum motion
Healthy amplitude confirms restored power and proper regulating action.
Troubleshooting Flowcharts
If the clock stops intermittently
Pivot wear → Upper‑train drag → Tooth burr → Contamination
If the pendulum swing is weak
Power loss → Pivot friction → Tooth wear → Train drag
If motion is uneven
Wear in regulating components → Pivot ovaling → Tooth burr → Misalignment
If the clock is tilt‑sensitive
Worn pivots → Reduced tolerance → Regulating friction → Weak power
If the movement surges
Intermittent drag → Pivot burr → Tooth contamination → Wear progression
Common Mistakes to Avoid
Oiling worn pivot holes
Oil masks the problem temporarily but accelerates wear.
Ignoring tooth wear
Even small burrs cause major timing issues.
Running the clock dirty
Dirt acts as an abrasive and increases friction.
Skipping pivot polishing
Rough pivots cause drag even after cleaning.
Testing only briefly
Wear‑related issues often appear after extended running.
Checklist for Final Verification
• Pivot holes round and tight
• Pivots polished
• Teeth clean and smooth
• Upper train free
• Pendulum amplitude strong
• Movement stable and reliable
FAQs
Why does wear show up here first?
High‑speed wheels are the most sensitive to friction.
Why does the clock stop randomly?
Intermittent friction or pivot wear is usually the cause.
Can this be repaired?
Yes—bushing, polishing, and cleaning restore proper function.
Why is the pendulum swing weak?
Power loss from upper‑train friction.
Is this common in these movements?
Yes—high‑speed components wear faster than lower‑train parts.
