Introduction
This article summarizes the conditions and repair steps as presented. The restoration focused on a 1906 Seth Thomas Adamantine clock case purchased in worn condition, with melted areas, bubbling, dull surfaces, and missing hardware.
Initial Condition of the Clock
Case appearance
The “cherry” Adamantine finish was mottled with wax, grease, soot, and tar. The lower front section showed an alligatoring-like texture.
Heat damage indicators
The finish appeared melted in places, suggesting long-term placement above a working fireplace.
Missing components
The hardware, face, movement, and back panel had already been removed before restoration began.
Surface contamination
Stubborn tar deposits remained in cracks and crevices even after initial cleaning.
Overall goal
Restore the case to a clean, glossy, factory-like appearance without replacing original material.
Cleaning and Surface Preparation
General cleaning
Murphy’s Oil Soap and Mother’s chrome cleaner were used to remove grime and buildup from most of the case.
Stubborn residue removal
Mineral spirits applied with swabs and toothpicks helped remove embedded tar from cracks.
Wet sanding for bubbled areas
600‑grit wet sanding was used sparingly to remove coarse, bubbled Adamantine. The surface was dried immediately after each pass.
Fine sanding
2000‑grit wet sanding refined the surface and removed remaining roughness.
Mineral‑spirits sanding
Additional 2000‑grit sanding dipped in mineral spirits helped smooth stubborn areas without harming the Adamantine.
Restoring Gloss and Engraving Detail
Polishing the surface
Meguiar’s Mirror Glaze was used to restore the mirror‑like shine lost during sanding.
Engraving color loss
Mineral spirits removed some of the black coloring from engraved details.
Recoloring the engravings
Tattered Angels tint wash was brushed on and wiped back, restoring the engraved black accents cleanly.
Refreshing interior and back surfaces
The tint wash was also used to refresh the black interior and back panel, improving overall appearance.
Final protective finish
Renaissance Wax was applied to seal and protect the restored surfaces.
Hardware and Bezel Refinishing
Hardware stripping and lacquering
All metal hardware was stripped and relacquered to restore its original appearance.
Bezel cleaning
The bezel was cleaned and relacquered, revealing the original brass and paper dial beneath.
Glass clarity
The door glass was cleaned thoroughly, appearing nearly invisible after restoration.
Original components retained
The bezel, paper dial, and glass were all original and preserved during the process.
Final appearance
The restored bezel and dial assembly matched the refreshed case, completing the transformation.
Observations About Adamantine Durability
Resistance to chemicals
The Adamantine surface tolerated cleaners, mineral spirits, and sanding without damage.
Heat sensitivity
The bubbling and coarse texture were likely caused by prolonged heat exposure.
Color and pattern realism
Wood‑grain imitation areas were noted to be impressively realistic.
Historical context
Adamantine was an early plastic known for durability and decorative versatility.
Value perspective
Despite their craftsmanship, these clocks are often undervalued today compared to their original cost relative to wages.
FAQs
How were bubbled areas repaired?
Through careful wet sanding with 600 and 2000 grit, followed by polishing.
What restored the shine?
Meguiar’s Mirror Glaze brought back the mirror finish.
How were engravings recolored?
Tattered Angels tint wash restored the black detailing.
Was the bezel original?
Yes, the original bezel, paper dial, and glass were retained and cleaned.
What protected the final finish?
Renaissance Wax provided the final protective layer.
