Regula 25 cuckoo clocks with overhead music boxes failing to start after cuckoo sequence reveal the critical adjustment problem where music stop lever pin falls back into drum hole rather than landing above hole preventing music drum rotation despite proper spring tension and adequate activation wire pull. When clockmakers encounter movements where music plays perfectly when manually triggered but fails during automatic operation, cuckoo completes normally but music remains silent, or music stop lever requires excessive force for extraction from drum hole, the frustrating diagnostic challenge occurs because music box triggering depends on precise coordination between activation lever pull distance, spring tension positioning stop pin above drum hole, and fly governor advancing fractionally during warning period allowing proper lever repositioning before rack drop releases music train. This complex timing problem happens because older Thorens-style music boxes use eccentric ledge on drum face where stop finger must jump outward following ledge circumference until dropping back into hole after complete revolution while simultaneously shorter pointed finger pulls into fly governor stopping mechanism creating interdependent timing requiring exact adjustment of both activation wire providing adequate outward pull and fan stop wire allowing proper fly movement during warning without premature music start. This guide covers complete Regula 25 music box trigger diagnosis and adjustment from understanding Thorens versus modern designs to achieving reliable operation. You'll learn identifying older Thorens music boxes through eccentric drum face ledge and radial stop finger motion rather than vertical movement, adjusting activation lever ensuring pin pulls out of hole "with authority" allowing spring to reposition pin decisively above hole, setting fan stop wire allowing fly quarter-turn during warning positioning mechanism properly before rack drop releases music, verifying drum positioning where pin-free section aligns with stopped position ensuring full tune plays without partial comb engagement, and recognizing when music box has been "monkeyed with" requiring professional restoration beyond field adjustment capabilities. The key to successful music box triggering is recognizing that stop lever doesn't actually stop drum but rather releases fly governor to land on warning wire where when rack drops at cuckoo sequence end warning wire drops allowing music train to run one complete drum revolution with stop finger dropping back into hole while simultaneously shorter finger pulls into fly stopping mechanism creating precise timing requiring both adequate activation lever pull and proper fly warning advance for reliable automatic triggering throughout all hours.
Understanding Regula 25 Music Box Architecture
Thorens Versus Modern Music Box Designs
Older Regula 25 music boxes often use Thorens mechanism distinguishable by drum design and stop lever operation. Thorens drum has eccentric ledge around face. When stop finger lifts from hole, it jumps outward following eccentric ledge circumference during rotation. After complete revolution, finger drops back into hole stopping mechanism. This radial motion - in and out - differs fundamentally from modern designs using vertical stop finger motion up and down relative to drum face.
Thorens design requires precise adjustment. Stop finger must follow eccentric ledge smoothly without binding or premature dropping. Ledge provides mechanical guidance ensuring finger remains out of hole during rotation. However, any misalignment between finger angle, spring tension, or activation lever travel prevents reliable ledge following. Finger may attempt to drop into hole before completing revolution creating jamming that prevents proper operation and makes subsequent activation increasingly difficult.
Modern music boxes simplify mechanism using flat drum face with stop finger moving vertically. Spring pulls finger upward clear of hole. After drum completes revolution, finger drops downward into hole. This vertical motion eliminates eccentric ledge complexity making adjustment more forgiving. However, many vintage Regula 25 clocks retain original Thorens mechanism requiring understanding of radial finger motion and eccentric ledge function for successful diagnosis and adjustment.
Dual Stop Mechanism Operation
Music box uses two separate stopping elements working together. Primary stop is finger dropping into drum hole. This occurs at specific rotational position corresponding to tune completion. However, finger alone doesn't stop drum immediately. After finger enters hole, drum continues rotating slightly. This additional rotation allows second stopping element - shorter pointed finger above primary stop - to pull approximately half millimeter into fly governor blades creating actual stopping force.
Timing between these elements is critical. If shorter finger pulls into fly before primary finger secures in drum hole, mechanism jams. Primary finger can't drop properly into hole because drum has stopped prematurely. If primary finger drops into hole but drum continues rotating excessively before shorter finger engages fly, mechanism may overshoot creating misalignment for next cycle. Proper adjustment achieves simultaneous engagement where primary finger drops into hole while shorter finger pulls into fly within fraction of rotation creating clean reliable stopping.
However, understanding proper sequence prevents misdiagnosis. Clockmaker observing that primary finger doesn't stop drum may incorrectly conclude mechanism is broken. Actually, primary finger positions mechanism for final stopping by shorter finger. Both elements must function correctly for reliable operation. Attempting to adjust primary finger for immediate drum stopping conflicts with design intent creating problems rather than solutions.
Warning Period Fly Movement
When activation lever lifts stop finger from drum hole, fly governor immediately advances fractionally landing on warning wire. This small advance - approximately quarter turn - positions mechanism for proper music start after cuckoo sequence completes. Warning wire prevents fly from continued rotation maintaining music box in ready position during cuckoo calling. When rack drops at sequence end, warning wire drops releasing fly allowing music drum to rotate.
This warning advance is essential for proper timing. Without warning advance, stop finger drops back into hole at same rotational position where it was extracted. Finger can't reposition above hole because mechanism hasn't advanced. With proper warning advance, mechanism rotates slightly allowing spring to pull finger above hole rather than directly back into hole. This repositioning enables reliable music start when rack drops releasing warning wire.
Fan stop wire controls warning advance. Wire must position correctly allowing fly quarter-turn movement when stop finger lifts but preventing excessive rotation that would start music prematurely during cuckoo sequence. Too restrictive wire position prevents adequate advance causing stop finger to drop back into hole. Too permissive wire position allows excessive advance starting music before cuckoo completes. Precise wire adjustment achieves proper warning advance without premature music start.
Diagnosing Music Box Triggering Problems
Testing Manual Versus Automatic Operation
Fundamental diagnostic distinction is whether music plays when manually triggered but fails during automatic operation. Manually push activation lever observing stop finger behavior. Finger should lift cleanly from drum hole with spring pulling it outward and upward clear of hole. Release lever allowing spring to control finger motion. Finger should not drop immediately back into hole but should remain clear allowing drum rotation if mechanism is released.
If manual operation works perfectly but automatic operation fails, problem is insufficient activation lever travel during automatic triggering. Wire connecting clock movement to music box activation lever doesn't pull lever far enough. Finger lifts partially from hole but not enough for spring to reposition it clear of hole. When wire releases at rack drop, finger immediately falls back into hole preventing drum rotation. This creates frustrating situation where music box appears functional during bench testing but fails during installed operation.
However, if manual operation also shows finger dropping back into hole, problem is within music box mechanism itself. Spring may be weak, damaged, or incorrectly positioned. Stop lever may be bent preventing proper finger positioning. Eccentric ledge on Thorens drum may be damaged preventing proper finger guidance. These internal problems require music box service rather than simple activation wire adjustment. Distinguishing between inadequate activation versus internal mechanism problems guides appropriate correction preventing wasted effort adjusting wrong components.
Observing Stop Finger Behavior
Watch stop finger carefully during activation. Finger should move decisively outward from drum hole not hesitantly or partially. Hesitant motion suggests inadequate spring tension or binding preventing proper movement. Partial motion indicates insufficient activation lever travel. Finger lifting completely clear of hole then immediately falling back suggests spring isn't pulling finger sufficiently sideways repositioning it above rather than aligned with hole.
On Thorens mechanisms, observe whether finger follows eccentric ledge during rotation. Remove fly governor temporarily allowing drum to rotate freely. Manually position stop finger in hole. Activate lever lifting finger. Slowly rotate drum by hand watching finger behavior. Finger should jump outward onto eccentric ledge then follow ledge circumference as drum rotates. After complete revolution, finger should drop back into hole. If finger doesn't track ledge smoothly, lever angle or spring positioning is incorrect requiring adjustment.
For modern vertical-motion mechanisms, observe whether finger rises adequately above drum face during activation. Finger must clear drum hole completely allowing rotation without interference. After rotation completes, finger drops vertically into hole from above. Any sideways motion or partial clearance indicates incorrect spring positioning or inadequate activation travel preventing reliable operation. Systematic observation during both manual and automatic operation reveals specific problem enabling targeted correction.
Checking Drum Positioning
Music drum has pin-free section where no pins contact comb during rotation. This blank section must align with stopped position ensuring music starts at tune beginning rather than mid-sequence. If drum stops with pins already contacting comb, music plays partial tune during next cycle creating incorrect musical sequence. Additionally, comb arms held by pins during stopped position create constant spring tension potentially causing premature wear or deformation.
Verify drum position by observing comb during stopped state. No comb arms should show deflection from pin contact. All arms should rest naturally without pins underneath. If arms show deflection, drum is positioned incorrectly requiring rotation to pin-free section. Remove fly governor allowing free drum rotation. Rotate drum until pin-free section aligns with comb. Reinstall governor with stop finger positioned in drum hole at this rotational position.
However, correcting drum position may require adjusting stop finger hole position or creating new hole if original positioning is incorrect. This extensive modification exceeds simple field adjustment requiring careful consideration. For valuable music boxes, professional service ensuring proper hole positioning without damaging drum is preferable. For common movements where drum replacement is economical alternative, new drum provides permanent correction without requiring delicate modification of original components.
Activation Lever Adjustment
Ensuring Adequate Pull Authority
Critical requirement for reliable triggering is activation lever pulling stop finger from hole "with authority" not tentatively or marginally. Adequate pull ensures finger lifts completely clear of hole allowing spring to reposition finger decisively. Marginal pull creates situation where finger partially lifts but doesn't clear sufficiently for spring repositioning. This marginal condition may work initially but becomes progressively less reliable as spring fatigues or mechanism accumulates slight wear.
Test activation lever travel by marking finger position in hole using non-permanent method. Operate activation lever through complete stroke. Measure how far finger moves from marked position. Movement should be substantial - approximately twice finger thickness minimum. Excessive movement wastes motion but doesn't harm operation. Insufficient movement prevents reliable clearing. If movement is marginal, increase activation lever travel through wire adjustment or lever repositioning.
Adjust activation wire length and routing ensuring adequate pull without excessive resistance. Wire should be taut when lever is at rest not slack allowing lost motion. However, wire shouldn't be so tight that it prevents proper lever return. Proper tension creates immediate response when clock movement operates activation mechanism while allowing free lever return when mechanism releases. Route wire avoiding sharp bends or friction points that create resistance preventing full lever travel despite adequate mechanism pull.
Adjusting Lever Angle and Spring Tension
Stop lever angle affects finger trajectory during activation. Lever bent excessively downward causes finger to lift straight outward without adequate upward component preventing repositioning above hole. Lever bent excessively upward creates steep trajectory potentially causing finger to bind against drum face during extraction. Optimal angle combines outward and upward motion creating clean extraction with adequate clearance for repositioning.
Spring provides return force pulling lever and finger to rest position. However, spring must also provide lateral force pulling finger sideways during activation positioning finger above hole rather than directly aligned with hole. This lateral component is essential for Thorens mechanisms where finger must engage eccentric ledge. Spring positioned pulling purely toward drum center doesn't provide adequate lateral force. Spring positioned pulling tangentially provides lateral component but may create binding during finger drop.
Optimal spring positioning balances these requirements. Spring pulls primarily toward drum center providing adequate return force while having slight tangential component providing lateral repositioning force. Adjust spring position incrementally testing operation after each change. Don't attempt dramatic spring repositioning in single adjustment. Multiple small adjustments converge on optimal position more reliably than attempting single correction potentially overshooting creating opposite problem requiring reverse adjustment wasting time and risking component damage.
Verifying Installation Clearance
Music box operating perfectly on bench may fail after installation in clock case. Clearance problems between music box components and case structure create interference preventing proper lever motion. Cabinet top may restrict lever travel. Case sides may interfere with wire routing creating friction preventing adequate pull. Mounting brackets may position music box at incorrect angle affecting lever geometry and spring function.
Test operation with music box in installed position before declaring success. Operate clock through complete cycle observing music triggering. If bench testing showed perfect operation but installed testing reveals problems, systematic inspection identifies interference source. Remove music box, correct interference through case modification or music box repositioning, reinstall, and retest. Continue iteration until installed operation matches bench testing performance ensuring reliable long-term operation.
However, some installations simply can't accommodate music box properly without extensive modification. Case design may be incompatible with music box dimensions or mounting requirements. Previous repairs may have altered case structure creating clearance problems. In these situations, alternative mounting approaches or music box omission may be necessary. Balance authentic restoration goals against practical functionality requirements making informed decisions based on clock value, customer expectations, and available correction options.
Fan Stop Wire Adjustment
Understanding Wire Function
Fan stop wire serves dual purpose. During cuckoo sequence, wire holds fly governor preventing music from starting prematurely. After cuckoo completes and rack drops, wire moves aside releasing fly allowing music drum rotation. However, wire must allow slight fly movement during warning period when stop finger first lifts from drum hole. This warning advance positions mechanism for proper music start when wire subsequently releases.
Wire positioning is critical. Too close to fly prevents adequate warning advance causing stop finger to drop back into hole. Too far from fly allows excessive movement starting music during cuckoo sequence. Optimal position allows approximately quarter-turn fly movement when stop finger lifts then prevents further movement until rack drops releasing wire completely. This precise positioning requires careful adjustment testing operation through multiple cycles verifying consistent reliable triggering.
However, wire itself may be damaged from previous service attempts. Bent or kinked wire prevents smooth operation creating inconsistent behavior. Wire should have gentle curves without sharp bends creating stress concentrations that risk breakage. Damaged wire requires straightening or replacement before adjustment proceeds. Attempting to adjust damaged wire creates frustration where optimal position can't be found because wire geometry prevents proper function regardless of positioning.
Progressive Adjustment Technique
Begin adjustment with wire positioned restrictively preventing any fly movement. Operate mechanism observing whether stop finger drops back into hole confirming diagnosis that insufficient warning advance is problem. If finger still drops into hole with restrictive wire position, problem is inadequate activation lever travel not wire positioning. Only proceed with wire adjustment after confirming adequate activation lever travel.
Move wire incrementally away from fly allowing progressively more movement. Test operation after each adjustment observing stop finger behavior. Goal is finding position where fly advances enough for finger repositioning without allowing premature music start. This optimal position has narrow adjustment window. Too little advancement fails to solve problem. Too much advancement creates different problem. Patient incremental adjustment finds optimal position more reliably than attempting large adjustments risking overshooting.
Document wire position using measurements or photographs. After finding optimal position, mark wire location relative to fixed reference preventing accidental displacement during subsequent handling. Wire may shift during music box installation or case assembly. Without documentation, rediscovering optimal position requires repeating entire adjustment process. Simple documentation prevents this wasted effort enabling quick restoration of optimal positioning if displacement occurs.
Coordinating Wire With Activation Timing
Fan stop wire and activation lever must coordinate properly. Wire releases at same moment rack drops completing cuckoo sequence. If wire releases before rack drops, music starts during final cuckoo creating overlapping sounds. If wire releases after rack drops, slight delay occurs before music starts creating gap in sound sequence. Proper coordination requires verifying activation lever and wire operate synchronously throughout movement operating cycle.
Test coordination by operating movement through complete hour cycle. Observe exact moment when activation lever releases relative to when rack drops. These should occur simultaneously within small fraction of second. Any significant timing mismatch indicates problem with movement mechanism rather than music box adjustment. Clock movement synchronization requires attention before music box adjustment can succeed. Attempting music box adjustment when movement timing is incorrect creates situation where music box adjustment compensates for movement problems creating unreliable operation requiring constant readjustment.
If movement timing is correct but coordination remains problematic, examine linkage between movement and music box. Wires may be incorrectly routed creating phase shift where activation occurs before or after intended point in cycle. Lever pivots may be worn creating lost motion affecting timing. These linkage problems require correction through proper routing, worn component replacement, or lever geometry adjustment rather than attempting to compensate through music box internal adjustment that creates marginally functional system prone to failure.
When Professional Service Is Necessary
Recognizing Monkeyed-With Music Boxes
Music boxes that have been "monkeyed with" by unskilled repairers show characteristic signs. Levers may be bent irregularly from repeated adjustment attempts. Springs may be repositioned incorrectly or replaced with inappropriate substitutes. Stop finger may show filing marks from attempts to modify geometry. Drum may have additional holes drilled from incorrect stop positioning attempts. These modifications typically make reliable adjustment impossible requiring restoration to original configuration.
Attempting field adjustment on damaged music box wastes time and creates frustration. Modifications interact creating complex problems without straightforward solutions. Each adjustment attempt creates additional problems as clockmaker tries compensating for previous inappropriate modifications. Better approach is recognizing situation early and seeking expert restoration rather than investing hours attempting corrections that ultimately prove unsuccessful. Professional restoration to original configuration provides permanent solution justifying cost through reliable long-term operation.
However, distinguishing appropriate previous service from inappropriate modifications requires experience and knowledge of original configuration. Some apparent modifications may actually be factory features or appropriate professional repairs. Don't immediately condemn music box based on superficial assessment. Careful examination comparing to documented examples or consulting experienced specialists determines whether music box requires restoration versus simple adjustment correcting minor issues.
Severe Wear Requiring Replacement
Worn music boxes may not respond adequately to adjustment. Pivot holes may be elongated creating excessive play preventing precise positioning. Springs may be fatigued providing inadequate force. Drum eccentric ledge may be worn preventing proper finger tracking. These wear conditions create situation where optimal adjustment position doesn't exist. Mechanism operates marginally at best regardless of adjustment effort requiring component replacement or complete music box replacement.
Assess wear severity through systematic inspection. Measure pivot clearances determining whether they exceed acceptable limits. Test spring tension comparing to known-good examples. Examine drum ledge under magnification checking for wear or damage. If multiple wear conditions exist, replacement is more practical than attempting to correct each individually. Balance repair cost against music box value and clock overall worth making informed decision about appropriate correction level.
Replacement music boxes must match original specifications. Tune, mounting dimensions, and triggering mechanism must be compatible with clock design. Generic music boxes may not fit properly or may require extensive modification for installation. Source replacements from reputable suppliers providing specifications and return options if compatibility problems arise. However, for valuable clocks, restoration of original music box preserves authenticity justifying higher cost compared to replacement with modern substitute creating historically incorrect configuration.
FAQs
Why does my music box work manually but not automatically?
Music box working perfectly when manually triggered but failing during automatic operation indicates insufficient activation lever travel during automatic triggering where wire connecting clock movement to music box doesn't pull lever far enough. Stop finger lifts partially from drum hole but not enough for spring to reposition it clear of hole and when wire releases at rack drop finger immediately falls back into hole preventing drum rotation. This creates frustrating situation where music box appears functional during bench testing but fails during installed operation. Increase activation lever travel through wire adjustment ensuring lever pulls stop finger from hole "with authority" not tentatively where adequate pull ensures finger lifts completely clear of hole allowing spring to reposition finger decisively. Test activation lever travel by marking finger position in hole and measuring movement during complete stroke where movement should be substantial approximately twice finger thickness minimum. Adjust activation wire length and routing ensuring adequate pull without excessive resistance where wire should be taut when lever is at rest not slack but shouldn't be so tight that it prevents proper lever return creating immediate response when mechanism operates while allowing free return when mechanism releases.
What is difference between Thorens and modern music box designs?
Thorens music boxes use eccentric ledge around drum face where stop finger jumps outward following ledge circumference during rotation creating radial motion in and out rather than vertical motion up and down used by modern designs. When stop finger lifts from hole it jumps outward following eccentric ledge until dropping back into hole after complete revolution. This radial motion requires precise adjustment where stop finger must follow eccentric ledge smoothly without binding or premature dropping and ledge provides mechanical guidance ensuring finger remains out of hole during rotation. Modern music boxes simplify mechanism using flat drum face with stop finger moving vertically where spring pulls finger upward clear of hole and after drum completes revolution finger drops downward into hole. Vertical motion eliminates eccentric ledge complexity making adjustment more forgiving though many vintage Regula 25 clocks retain original Thorens mechanism requiring understanding of radial finger motion and eccentric ledge function. Identify Thorens mechanism through visual inspection observing eccentric raised ledge on drum face and testing stop finger motion where radial movement indicates Thorens while vertical movement indicates modern design.
How do I adjust the fan stop wire?
Adjust fan stop wire allowing approximately quarter-turn fly movement during warning period when stop finger first lifts from drum hole then preventing further movement until rack drops releasing wire completely. Begin adjustment with wire positioned restrictively preventing any fly movement and operate mechanism observing whether stop finger drops back into hole confirming insufficient warning advance is problem. Move wire incrementally away from fly allowing progressively more movement testing operation after each adjustment where goal is finding position allowing fly advancement for finger repositioning without allowing premature music start. Optimal position has narrow adjustment window where too little advancement fails to solve problem while too much advancement allows music to start during cuckoo sequence. Wire itself may be damaged from previous service attempts where bent or kinked wire prevents smooth operation requiring straightening or replacement before adjustment proceeds. Document wire position using measurements or photographs after finding optimal position marking wire location relative to fixed reference preventing accidental displacement. Coordinate wire release timing with rack drop ensuring simultaneous operation within small fraction of second where any significant timing mismatch indicates problem with movement mechanism rather than music box requiring clock movement synchronization before music box adjustment can succeed.
Why does stop finger fall back into hole?
Stop finger falling back into hole rather than landing above hole indicates inadequate activation lever travel preventing finger from lifting completely clear or inadequate spring tension failing to reposition finger sideways above hole. Finger must lift outward from drum hole with spring pulling it sufficiently sideways that when lever releases finger repositions above hole rather than directly aligned with hole. Additionally fly governor must advance fractionally during warning period rotating mechanism slightly so finger drops at different rotational position than where it was extracted. Without warning advance mechanism hasn't rotated allowing spring to pull finger above hole. Fan stop wire controls warning advance where wire must allow quarter-turn fly movement when stop finger lifts but prevent excessive rotation starting music prematurely. Lever angle affects finger trajectory where lever bent excessively downward causes finger to lift straight outward without adequate upward component while lever bent excessively upward creates steep trajectory potentially causing binding. Spring positioning must balance return force pulling lever toward drum center with lateral force pulling finger sideways during activation where optimal spring positioning provides both adequate return and lateral repositioning components enabling reliable operation.
How do I know if drum is positioned correctly?
Correct drum position aligns pin-free section with stopped state where no pins contact comb ensuring music starts at tune beginning rather than mid-sequence. Verify drum position by observing comb during stopped state where no comb arms should show deflection from pin contact and all arms should rest naturally without pins underneath. If arms show deflection drum is positioned incorrectly requiring rotation to pin-free section where you remove fly governor allowing free drum rotation, rotate drum until pin-free section aligns with comb, and reinstall governor with stop finger positioned in drum hole at this rotational position. Comb arms held by pins during stopped position create constant spring tension potentially causing premature wear or deformation while also causing music to play partial tune during next cycle creating incorrect musical sequence. However correcting drum position may require adjusting stop finger hole position or creating new hole if original positioning is incorrect where this extensive modification exceeds simple field adjustment. For valuable music boxes professional service ensuring proper hole positioning without damaging drum is preferable while for common movements drum replacement provides permanent correction without requiring delicate modification of original components.
What does it mean when music box has been monkeyed with?
Music box that has been "monkeyed with" shows characteristic signs of unskilled repair attempts where levers may be bent irregularly from repeated adjustment attempts, springs may be repositioned incorrectly or replaced with inappropriate substitutes, stop finger may show filing marks from attempts to modify geometry, or drum may have additional holes drilled from incorrect stop positioning attempts. These modifications typically make reliable adjustment impossible requiring restoration to original configuration where modifications interact creating complex problems without straightforward solutions. Each adjustment attempt creates additional problems as clockmaker tries compensating for previous inappropriate modifications making better approach recognizing situation early and seeking expert restoration rather than investing hours attempting corrections that ultimately prove unsuccessful. Professional restoration to original configuration provides permanent solution justifying cost through reliable long-term operation. However distinguish appropriate previous service from inappropriate modifications through careful examination comparing to documented examples or consulting experienced specialists where some apparent modifications may actually be factory features or appropriate professional repairs. Normally there are no more than two adjustments to make which are whisker wire and actuation lever wire and these can easily get bent or misplaced when removing or replacing movement requiring precise readjustment but adjustments to music box itself should be carefully considered indicating wear or prior tampering requiring expert attention.
Should I remove music box from case for adjustment?
Yes remove music box from clock case for initial adjustment and testing where removal provides unrestricted access to all components enabling clear observation of mechanism operation during adjustment attempts. Music box operating perfectly on bench may fail after installation in clock case where clearance problems between music box components and case structure create interference preventing proper lever motion. Cabinet top may restrict lever travel, case sides may interfere with wire routing creating friction, or mounting brackets may position music box at incorrect angle affecting lever geometry and spring function. Test operation with music box in installed position after achieving successful bench operation before declaring success where if bench testing showed perfect operation but installed testing reveals problems systematic inspection identifies interference source. Remove music box, correct interference through case modification or music box repositioning, reinstall and retest continuing iteration until installed operation matches bench testing performance. However for final verification and adjustment of fan stop wire interaction with clock movement operation some testing must occur with music box installed and movement operating through complete cycles verifying coordination between activation lever release and rack drop timing ensuring synchronous operation throughout hour cycle.
