Introduction
This article summarizes the conditions and repair steps as presented. The focus is on replacing missing molding on a Waterbury wall clock and determining suitable methods for recreating decorative trim and round elements.
Initial Assessment of the Missing Molding
Clock type and condition
The Waterbury wall clock was missing sections of its top molding, including a quarter‑round decorative disk and a length of shaped trim.
Existing woodworking experience
The restorer had experience making replacement bottom trim but not carved or shaped molding.
Comparison to past projects
Previous restoration work included creating latex molds for ceiling medallions and keyhole covers, prompting questions about whether the same process applied here.
Material differences
The molding on the clock appeared to be wood, while the picture frame molding in question resembled resin or cast material.
Goal
Determine the most efficient and accurate method to recreate the missing pieces.
Woodworking Approaches for Replacement Pieces
Router‑based shaping
A router with the correct bit could be used to cut grooves and profiles for the straight molding sections.
Router table setup
Using a router table or table saw extension allows controlled shaping of long trim pieces.
Round disk fabrication
A round disk could be shaped using a router and guide blocks to hold the piece steady while rotating it.
Mitering replacement trim
Once shaped, the new molding can be mitered to match the existing pieces.
Tool considerations
Additional router bits may be required, offering an opportunity to expand tooling.
Lathe‑Based Solutions
Turning the round element
The quarter‑round decorative disk could be turned on a lathe using a faceplate.
Cutting into sections
After turning, the disk can be cut into four equal pieces, allowing replacement of both missing sections for symmetry.
Finial replacement
The clock appeared to be missing a finial, which can be easily turned on a lathe or purchased pre‑made.
Alternative for non‑lathe users
Pre‑made wooden rosettes can be purchased and cut to size if a lathe is unavailable.
Matching existing details
Using turned pieces ensures consistent curvature and a close match to the original design.
Casting and Mold‑Making Options
Latex mold duplication
Latex molds can be made from intact sections of molding, similar to methods used for ceiling medallions.
Suitable casting materials
Hydrocal plaster was recommended as a strong casting material, superior to plaster of Paris.
Brush‑on mold compounds
Products like Rub‑R‑Mold can be brushed on in layers to create flexible molds.
Pour‑over mold compounds
Thicker compounds such as Amazing Clear Cast can be poured over the original to create a one‑piece mold.
Reinforcing the mold
Plaster can be poured over the rubber mold to create a rigid support shell before casting.
Fitting and Finishing Replacement Pieces
Cutting and fitting
Cast or turned pieces should be cut cleanly and fitted precisely into the missing areas.
Adhesive selection
Epoxy was recommended for attaching replacement molding securely.
Surface blending
Spackle can be used to fill joints and smooth transitions before finishing.
Color matching
Stain or paint should be applied to match the original finish as closely as possible.
Final appearance
Properly shaped and finished replacements restore the clock’s original decorative profile.
FAQs
What is the easiest way to make the round molding?
Turning a disk on a lathe and cutting it into quarters.
Can a router be used instead?
Yes, a router with the correct bit can shape both round and straight sections.
Is casting a good option?
Yes, latex or rubber molds can be used to duplicate decorative trim.
What material works best for casting?
Hydrocal plaster provides strength and detail.
How should replacement pieces be attached?
Epoxy and careful fitting ensure a secure, seamless repair.
