Introduction
When servicing an Urgos movement, one common question is whether the pendulum swing is wide enough for stable operation. A narrow swing may indicate power loss, verge misalignment, or escape wheel issues. This guide explains what a normal pendulum swing looks like in an Urgos movement, how verge depth affects amplitude, and how to diagnose problems using overswing and lock behavior.
Understanding Pendulum Swing in Urgos Movements
Typical swing range
Most grandfather clocks, including Urgos models, produce a total pendulum swing of around 3 inches, and some can exceed 5 inches.
Why swing amplitude matters
A wider swing increases pendulum momentum, making the clock more resistant to vibration and accidental stopping.
Overswing as the key indicator
Overswing—the distance the pendulum continues after the tick—is more important than total swing. Adequate overswing indicates healthy power delivery.
When small swing is acceptable
If the clock keeps time and shows clear overswing, the movement may be functioning correctly even with a modest swing.
When small swing signals trouble
Minimal overswing or inconsistent unlocking suggests power loss, friction, or verge/escape wheel issues.
How Verge Depth Affects Swing
Moving the verge closer
Reducing the distance between the verge and escape wheel increases swing amplitude—but only to a point. Too close and the pendulum may not unlock properly.
Moving the verge farther away
Increasing the distance reduces swing and may cause weak impulse or stalling.
Deadbeat vs recoil behavior
Urgos movements use a deadbeat escapement. In a proper deadbeat, the escape wheel teeth must land on the dead face, not the impulse face.
Incorrect lock behavior
If teeth land on the impulse face, the escapement behaves like a recoil, altering swing and reducing stability.
Finding the “sweet spot”
Auto‑beat Urgos verges have a narrow optimal depth. Too deep and the pallets bottom out; too shallow and the clock loses lock.
Diagnosing Power Loss
Check verge and escape wheel pivots
Even slight wear or lost motion in these pivots dramatically reduces pendulum amplitude.
Check for crooked or tight bushings
Improperly installed bushings can choke the train and reduce impulse power.
Inspect escape wheel teeth
Worn or short tooth tips make proper lock impossible and reduce swing.
Check for recoil
Any visible recoil indicates the tooth is landing on the impulse face, not the dead face, and must be corrected.
Evaluate overswing
If overswing is minimal, the movement is losing power somewhere in the train.
Troubleshooting Flowcharts
If the pendulum swing is too small
Check overswing → Check verge depth → Check escape wheel lock → Check verge/escape wheel pivots → Check for tight bushings
If the clock keeps time but swing is small
Verify overswing → Confirm deadbeat lock → Inspect escape wheel teeth → Evaluate pivot wear
If the clock stops easily
Increase verge depth slightly → Check for recoil → Inspect for power loss in train
Common Mistakes to Avoid
Chasing swing instead of overswing
Total swing is less important than healthy overswing.
Over‑deepening the verge
Too much lock increases friction and reduces impulse.
Ignoring pivot wear
Even tiny wear in the verge or escape wheel pivots severely reduces amplitude.
Assuming a new pendulum fixes everything
Pendulum replacement does not compensate for escapement issues.
Misinterpreting deadbeat behavior
Deadbeat escapements naturally have smaller swings than recoil types.
Checklist for Final Verification
• Escape wheel teeth land on dead face
• Clear overswing on both sides
• Verge depth in correct range
• No recoil visible
• Urgos movement runs steadily
• Pendulum swing stable and consistent
FAQs
Is 1¾ inches of swing enough?
It may be, if overswing is present and the clock keeps time.
Does moving the verge closer increase swing?
Yes, but only within limits. Too close causes unlocking failure.
Why does pivot wear affect swing so much?
Lost motion in the verge or escape wheel reduces impulse power dramatically.
Do Urgos movements require large swings?
No. Proper deadbeat operation often produces modest but stable swings.
What indicates proper lock?
The escape wheel tooth must land clearly on the dead face without recoil.
