Introduction
New Haven 8‑day movements rely on secure mainspring engagement between the inner coil, the arbor hook, and the barrel post. When the spring slips, fails to wind, or loses power suddenly, the cause is usually a worn post, damaged hook, or incorrect spring installation. This guide explains how the system works and how to diagnose common mainspring‑post issues.
How New Haven Mainspring Posts Work
Arbor hook engagement
The inner coil of the mainspring must hook securely onto the arbor to transmit torque.
Barrel post function
The outer end of the spring anchors to a post or tab inside the barrel, preventing rotation.
Spring tension and power delivery
Proper engagement ensures smooth, consistent power throughout the 8‑day run.
Common wear points
Worn posts, rounded hooks, or distorted spring ends cause slipping and weak running.
Importance of correct spring size
Oversized or undersized springs stress the post and reduce reliability.
Common Mainspring‑Post Problems
Spring slipping off the post
Indicates a worn or rounded post that no longer holds the spring securely.
Spring not winding fully
Often caused by a damaged arbor hook or incorrect spring orientation.
Sudden power loss
Occurs when the spring jumps off the post during winding or unwinding.
Uneven running
Spring distortion or barrel drag reduces torque and causes erratic performance.
Barrel wall scoring
Indicates the spring is scraping due to misalignment or incorrect seating.
How to Diagnose the Issue
Inspect the barrel post
Look for rounding, wear, or metal fatigue—posts must have a sharp, defined edge.
Check the spring end
Ensure the outer coil is shaped correctly to catch the post without slipping.
Verify arbor hook condition
Worn or bent hooks prevent proper engagement with the inner coil.
Check spring size
Incorrect width or thickness stresses the post and causes slippage.
Test barrel rotation
The barrel should rotate smoothly with no scraping or binding.
Correcting the Problem
Step 1: Reform the spring end
Shape the outer coil so it seats firmly against the post.
Step 2: Repair or replace the post
Posts can be rebuilt, replaced, or reinforced depending on wear.
Step 3: Correct the arbor hook
Sharpen or reshape the hook to ensure secure engagement.
Step 4: Install the correct spring
Use a spring that matches original specifications for width, thickness, and length.
Step 5: Reassemble and test
Wind partially and verify the spring holds securely without slipping.
Troubleshooting Flowcharts
If the spring slips during winding
Post worn → Spring end distorted → Arbor hook weak → Wrong spring size
If the movement runs weakly
Spring set → Barrel drag → Pivot wear → Incorrect lubrication
If the spring jumps off the post
Post rounded → Spring end too open → Barrel distortion → Excessive torque
If the clock stops early
Spring fatigue → Hook slipping → Barrel friction → Power loss
If the barrel scrapes
Spring misaligned → Barrel wall scored → Arbor off‑center → Bent barrel
Common Mistakes to Avoid
Using oversized springs
Too much torque damages posts and hooks.
Prying the barrel lid
Distorts the barrel and causes drag.
Ignoring post wear
Even slight rounding causes slippage under load.
Over‑lubricating
Excess oil attracts dirt and increases drag.
Skipping spring inspection
Hidden cracks or distortion cause intermittent power loss.
Checklist for Final Verification
• Spring seated correctly
• Post secure and sharp
• Arbor hook engages firmly
• Barrel rotates freely
• Power delivery strong
• Movement runs full duration
FAQs
Why does my mainspring slip off the post?
The post is likely worn or the spring end is incorrectly shaped.
Why won’t the spring wind fully?
The arbor hook may be worn or the spring may be installed incorrectly.
Should I replace the spring?
Replace if cracked, distorted, or severely set.
Can the post be repaired?
Yes—posts can be rebuilt or replaced depending on condition.
Is this common in New Haven movements?
Yes—post wear and spring distortion are frequent issues in older examples.
