Introduction
Suspension springs are critical to accurate pendulum operation. When the original spring is missing, damaged, or the wrong thickness, a clock may run fast, slow, or fail to maintain a stable beat. Making a suspension spring from scratch is straightforward with the right materials and careful shaping. This guide explains how to fabricate a reliable suspension spring and ensure proper alignment with the pendulum rod and crutch.
Understanding Suspension Springs
Function
The suspension spring supports the pendulum while allowing free oscillation with minimal friction.
Material
Typically made from thin, hardened spring steel or phosphor‑bronze ribbon.
Thickness
Spring thickness affects rate—thicker springs run faster, thinner springs run slower.
Flexibility
The spring must flex evenly without twisting or binding.
Mounting
Suspension blocks hold the spring at the top and bottom, connecting it to the pendulum rod.
Materials Needed
Spring steel or phosphor‑bronze strip
Choose a thickness close to the original or based on movement design.
Sharp shears or jeweler’s snips
Used to cut the spring material cleanly.
Fine file or stone
For smoothing edges after cutting.
Suspension blocks
Top and bottom blocks clamp the spring securely.
Calipers
Used to measure thickness and width accurately.
How to Make a Suspension Spring
Step 1: Determine the correct thickness
Match the original if available; otherwise, use typical values for the movement type.
Step 2: Cut the spring strip
Cut slightly longer than needed, then trim to final length.
Step 3: Smooth the edges
Remove burrs to prevent stress points that could cause cracking.
Step 4: Install the top block
Clamp the spring securely without crushing or bending it.
Step 5: Install the bottom block
Ensure the spring hangs straight and the block aligns with the pendulum rod.
Common Problems and Their Causes
Clock runs fast
Spring too thick or too short.
Clock runs slow
Spring too thin or too long.
Pendulum wobbles
Spring twisted or blocks misaligned.
Beat unstable
Crutch not centered or spring not hanging straight.
Spring breaks prematurely
Sharp edges, burrs, or excessive bending during installation.
Troubleshooting Flowcharts
If the clock runs fast
Spring too thick → Spring too short → Crutch too tight → Pendulum too light
If the clock runs slow
Spring too thin → Spring too long → Pendulum too heavy → Crutch slipping
If the pendulum wobbles
Spring twisted → Blocks misaligned → Rod bent → Crutch interference
If the beat is uneven
Spring off‑center → Crutch misaligned → Case not level → Suspension block loose
If the spring breaks
Burrs on edges → Excess bending → Incorrect material → Over‑tightened blocks
Common Mistakes to Avoid
Using the wrong thickness
Even small deviations affect timekeeping.
Leaving burrs on the edges
Burrs create stress points that lead to cracking.
Over‑tightening the blocks
Crushing the spring weakens it and causes premature failure.
Twisting the spring during installation
Twist causes wobble and unstable beat.
Guessing the length
Measure carefully—length affects rate significantly.
Checklist for Final Verification
• Spring thickness correct
• Edges smooth
• Blocks aligned
• Spring hangs straight
• Pendulum stable
• Beat even and strong
FAQs
Can I use any thin metal strip?
No—only hardened spring steel or phosphor‑bronze works properly.
How do I know the right thickness?
Match the original or use known values for the movement type.
Why does the pendulum wobble?
The spring is twisted or the blocks are misaligned.
Can I reuse old blocks?
Yes, if they clamp securely and align properly.
Is this common in antique clocks?
Yes—suspension springs often break or go missing and must be replaced.
