Introduction
Worn verge pallets are common in antique clocks. Deep ruts, poor past repairs, or incorrect geometry can prevent proper lock, drop, and impulse with the escape wheel. When adjustment is no longer possible, a new verge must be fabricated. Using the original verge as a template ensures correct geometry and span. This guide explains how to make a replacement verge using gauge plate tool steel, how to shape and finish the impulse faces, and how to test the new verge in the movement while mounted on a movement stand.
Understanding Verge Wear and Failure
Why verge pallets wear
Escape wheel teeth strike the impulse faces thousands of times per hour, eventually cutting grooves or ruts.
When adjustment is no longer possible
If ruts are centered or span the full impulse face, shifting the verge on its arbor will not expose fresh surface.
Problems caused by worn pallets
Worn pallets cause flutter, loss of lock, poor drop, and inconsistent pendulum motion.
Why replacement is sometimes required
Bad past repairs—such as slips soldered on, uneven grinding, or incorrect pallet angles—can distort geometry beyond correction.
Using the original as a template
The original verge provides the correct span, pallet angles, and overall shape needed for a proper replacement.
Preparing the Gauge Plate
Selecting the steel
Gauge plate (O1 tool steel) is ideal because it is dimensionally accurate, machines well, and hardens reliably.
Drill the arbor hole
Drill a snug hole for the verge arbor. If a brass collet is used, enlarge the hole to fit the collet.
Blue the steel
Apply layout dye or a blue Sharpie to the surface, leaving small unblued areas for superglue adhesion.
Glue the original verge to the plate
Superglue the original verge onto the gauge plate to hold it securely during scribing.
Scribe the outline
Use a hardened scribe to trace the exact shape of the original verge, cutting through the blue into the steel.
Shaping the New Verge
Remove excess steel
Use a saw, mill, or files to remove material up to—but not past—the scribed line.
Shape the underside
A large half‑round file works well for shaping the underside curve of the verge.
Rough in the impulse faces
Use a mill or careful filing to create the initial pallet faces. Leave extra material for fine adjustment.
Test fit repeatedly
The verge must be installed and removed many times to check lock, drop, and span with the escape wheel.
Adjust drop and span
Remove small amounts of steel at a time. You can always take more off—you can’t put it back.
Hardening and Tempering
Prepare for hardening
Finish the impulse faces to around 2500 grit before hardening. Finer grits make scale removal difficult.
Heat to cherry red
Heat the verge ends until non‑magnetic. This ensures the steel has reached the correct phase for hardening.
Quench in oil
Quench in oil while moving the piece to reduce scale and prevent warping.
Temper in an oven
Temper at approximately 240°C (464°F) for one hour. The steel should turn a straw color.
Final polish
Finish the impulse faces with progressively finer papers up to 7000 grit, then polish with a felt wheel.
Testing the New Verge
Mount the movement on a stand
A movement stand provides stability and allows clear access to the escape wheel for testing.
Check lock
Each escape wheel tooth must lock securely on the entry and exit pallets.
Check drop
Drop should be even on both pallets and match the original verge geometry.
Check impulse
The escape wheel must deliver a clean, consistent impulse to the pendulum.
Verify span
The span between pallets must match the original to maintain proper escapement timing.
Troubleshooting Flowcharts
If the escape wheel flutters
Check lock → Reduce impulse face angle → Verify pallet depth → Check verge arbor position
If drop is uneven
Adjust pallet angles → Re‑test → Verify scribed geometry → Check escape wheel trueness
If the clock loses power
Check pallet polish → Check verge alignment → Check escape wheel tooth condition
Common Mistakes to Avoid
Removing too much material
Always work up to the scribed line—never past it.
Skipping repeated testing
Verge geometry must be checked in the movement, not just on the bench.
Overheating during hardening
Use the magnet test to ensure proper temperature before quenching.
Failing to temper
Untempered steel is brittle and may chip or crack.
Not using a movement stand
Testing without a stand risks bent pivots and inaccurate adjustments.
Checklist for Final Verification
• Impulse faces polished
• Lock and drop correct
• Span matches original
• Escape wheel runs smoothly
• Verge hardened and tempered
• Movement stable on movement stand
FAQs
Why use gauge plate steel?
It machines cleanly, hardens well, and maintains precise thickness.
Why glue the original verge to the steel?
It ensures accurate scribing and geometry transfer.
Why test repeatedly?
Small adjustments dramatically affect escapement performance.
Why harden only the pallet ends?
It preserves adjustability while protecting the working surfaces.
Why use a movement stand?
It provides stability and access for accurate escapement testing.
