Introduction
Selecting the correct winding key size is essential for safe and reliable clock operation. A key that is too small will slip and round the arbor, while a key that is too large can twist or distort the square. This guide explains how winding key sizes are measured, how to determine the correct fit, how American and Swiss sizing differ, and why measuring the winding arbor is the only guaranteed method for choosing the correct key.
Understanding Winding Key Sizes
How key sizes are measured
Winding key sizes correspond to the width of the square on the winding arbor. This measurement is taken across the flats, not the corners.
Why precision matters
A proper fit ensures smooth winding and prevents wear on both the key and the arbor.
Standard sizing systems
Two major sizing systems exist: American and Swiss. Both use the same size numbers, but the actual millimeter measurements differ.
Differences between double-ended and single keys
Double-ended keys often include a hand-setting end, while single keys are dedicated solely to winding.
When a custom key is needed
Rare or unusual arbors may require a specially fitted key if standard sizes do not match.
How to Measure the Winding Arbor
Using calipers
Measure the width of the square across the flats. This provides the most accurate reading.
Using a key gauge
A key gauge allows quick comparison of arbor size to standard key openings.
Testing fit
The correct key should slide on easily but without noticeable play. A loose fit accelerates wear.
Checking for wear
Worn arbors may appear smaller than their original size. Inspect for rounding or distortion.
Accounting for taper
Some arbors are slightly tapered. Choose a key that fits the upper portion of the square securely.
Winding Key Size Conversion Chart
The following chart lists standard winding key sizes in millimeters, showing both American and Swiss measurements from smallest to largest. Measurements are taken across the flats of the square.
| Key Size | American (mm) | Swiss (mm) |
|---|---|---|
| 5/0 | 1.6 | 1.25 |
| 4/0 | 1.8 | 1.5 |
| 3/0 | 2.0 | 1.75 |
| 2/0 | 2.2 | 2.0 |
| 0 | 2.4 | 2.25 |
| 1 | 2.6 | 2.5 |
| 2 | 2.8 | 2.75 |
| 3 | 3.0 | 3.0 |
| 4 | 3.2 | 3.25 |
| 5 | 3.4 | 3.5 |
| 6 | 3.6 | 3.75 |
| 7 | 3.8 | 4.0 |
| 8 | 4.0 | 4.25 |
| 9 | 4.2 | 4.5 |
| 10 | 4.4 | 4.75 |
| 11 | 4.6 | 5.0 |
| 12 | 4.8 | 5.25 |
| 13 | 5.0 | 5.5 |
| 14 | 5.2 | 5.75 |
| 15 | 5.4 | 6.0 |
| 16 | 5.6 | 6.25 |
| 17 | 5.8 | 6.5 |
| 18 | 6.0 | 6.75 |
| 19 | 6.2 | 7.0 |
| 20 | 6.4 | 7.25 |
| 21 | 6.6 | 7.5 |
| 22 | 6.8 | 7.75 |
| 23 | 7.0 | 8.0 |
Why a Number 7 Key Is Not the Same in American and Swiss Sizes
Different systems, same number
Although both systems use the number “7,” the actual millimeter sizes differ. According to the chart:
- American #7 key = 3.8 mm
- Swiss #7 key = 4.0 mm
Why this matters
A 0.2 mm difference may seem small, but in clock winding squares it is significant. A Swiss #7 key may feel loose on an American #7 arbor, while an American #7 may not fit a Swiss #7 arbor at all.
The only reliable method
Because the numbering systems do not match perfectly, the only guaranteed way to select the correct key is to measure the winding arbor directly. Matching the arbor measurement to the chart ensures the correct key is chosen the first time.
Common Problems Caused by Incorrect Key Size
Slipping during winding
A key that is too small will slip and damage the corners of the arbor.
Twisting the arbor
An oversized key can apply uneven torque and twist the square.
Difficulty winding
A poor fit increases friction and makes winding harder than necessary.
Accelerated wear
Repeated use of the wrong key size leads to long-term damage.
Incorrect assumptions
Not all clocks use the same key size, even within the same brand or model line.
Tips for Selecting the Right Key
Start with a size close to your measurement
Choose the nearest standard size and test the fit carefully.
Try multiple keys
Small differences in manufacturing can affect fit. Testing several keys ensures accuracy.
Check both winding arbors
Some clocks use different key sizes for time and strike trains.
Inspect the key itself
Worn or distorted keys should be replaced, even if they originally fit correctly.
Keep a reference set
A set of standard key sizes makes future identification easier.
Troubleshooting Flowcharts
If the key slips
Check arbor wear → Try next size up → Inspect key opening → Replace worn key
If the key binds
Check for taper → Try next size down → Inspect arbor for burrs → Clean key opening
If winding feels uneven
Check arbor condition → Inspect mainspring → Verify key fit → Check lubrication
Common Mistakes to Avoid
Guessing the size
Always measure—visual estimation is unreliable.
Using a worn key
Worn openings distort the fit and damage the arbor.
Assuming all clocks use the same size
Even similar clocks may require different keys.
Ignoring taper
Tapered arbors require careful key selection.
Forcing the key
Forcing a tight key can twist or crack the arbor.
Checklist for Final Verification
• Key fits snugly without play
• No slipping during winding
• Arbor corners clean and sharp
• Correct size confirmed for both trains
• Key opening free of wear or distortion
• Winding smooth and consistent
FAQs
How do I know if a key is too small?
If it slips or rocks on the arbor, it is undersized.
Can a worn arbor be repaired?
Yes. A worn square can be re-shaped or sleeved by a qualified repairer.
Do all clocks use standard key sizes?
Most do, but some require custom or metric keys.
Why do some clocks have two key sizes?
Time and strike trains may use different arbor dimensions.
Should I keep extra keys?
A reference set makes future identification quick and accurate.
