Introduction
Junghans strike movements rely on precisely aligned hammer heads to produce a clear, consistent tone. When the hammer heads are bent, misaligned, or worn, the strike becomes weak, uneven, or noisy. This guide explains how Junghans hammer heads are designed, how to adjust them correctly, and how to diagnose strike issues caused by hammer lift, lever drag, or power loss in the train.
Understanding Junghans Hammer Head Design
Hammer head material
Junghans typically used hardened steel or brass hammer heads. Their weight and shape influence tone and rebound.
Hammer tail and lift relationship
The hammer tail rides on a lift pin or cam. Proper lift height ensures a strong strike without overstressing the hammer spring.
Rebound action
The hammer must rebound immediately after striking the rod or gong. Delayed rebound causes buzzing or muted tone.
Head curvature
Some Junghans hammer heads are slightly curved to match the contour of the chime rod or gong coil.
Wear points
Repeated striking can flatten or deform the hammer face, reducing clarity and volume.
Diagnosing Strike Problems
Weak strike
Often caused by insufficient hammer lift, worn hammer springs, or power loss in the strike train.
Buzzing or rattling
Occurs when the hammer rests too close to the rod or fails to rebound cleanly.
Double striking
Usually caused by excessive lift or a hammer head that bounces due to improper alignment.
Uneven tone
Misaligned hammer heads strike the rod at an angle, producing inconsistent sound.
Strike train stalling
Binding in the 2nd wheel or worn pivots can reduce power and prevent proper hammer lift.
Adjusting Junghans Hammer Heads
Step 1: Set the resting distance
The hammer should rest just off the rod or gong—close enough for efficient lift, but not touching.
Step 2: Align the hammer face
The hammer head must strike the rod squarely. Bend the hammer arm slightly if needed to correct angle.
Step 3: Adjust lift height
Lift should be high enough for a strong strike but not so high that the hammer bounces or stresses the spring.
Step 4: Check spring tension
The hammer spring must return the hammer quickly. Weak springs cause sluggish rebound.
Step 5: Verify clearance
Ensure the hammer does not rub the case, movement, or adjacent hammers.
Strike Train Power and the 2nd Wheel
Role of the 2nd wheel
The 2nd wheel drives the upper strike train and directly influences hammer lift strength.
Common wear points
Worn pivots, oval pivot holes, or dirty bushings reduce power and weaken the strike.
Checking freedom
Spin the 2nd wheel lightly. It should rotate freely and stop gradually.
Lubrication
Apply a small amount of oil to the 2nd wheel pivots only. Excess oil attracts dirt and reduces power.
Testing under load
Advance the minute hand to trigger the strike and observe whether the 2nd wheel delivers consistent lift.
Troubleshooting Flowcharts
If the strike is weak
Check hammer lift → Check hammer spring → Check 2nd wheel power → Check pivot lubrication
If the hammer buzzes
Increase resting distance → Check rebound → Adjust hammer angle → Inspect spring tension
If the hammer double-strikes
Reduce lift → Check hammer face alignment → Inspect rod clearance → Verify spring strength
If the strike stalls
Check 2nd wheel pivots → Check bushing wear → Check lift cam → Check hammer drag
If tone is uneven
Align hammer head → Check rod position → Inspect hammer face wear → Verify lift consistency
Common Mistakes to Avoid
Over-bending hammer arms
Excessive bending weakens the metal and causes long-term misalignment.
Oiling hammer joints
Hammer pivots and levers must run dry. Oil causes sluggish movement and delayed rebound.
Ignoring 2nd wheel wear
Power loss in the 2nd wheel affects the entire strike train.
Setting lift too high
High lift causes bounce, noise, and premature wear.
Letting the hammer rest on the rod
This kills tone and prevents proper vibration.
Checklist for Final Verification
• Hammer head aligned squarely
• Resting distance correct
• Lift height balanced
• Hammer spring strong and responsive
• 2nd wheel delivering full power
• Strike tone clear and consistent
FAQs
Why is my Junghans strike weak?
Often due to low power from the 2nd wheel or insufficient hammer lift.
Should I oil the hammer mechanism?
No. Only pivots receive oil—never the hammer arms or levers.
Why does the hammer bounce?
Lift is too high or the hammer head is misaligned.
Can worn hammer heads be reshaped?
Yes. Light filing and polishing can restore a clean striking surface.
Why does the strike stall halfway?
Likely due to worn 2nd wheel pivots or excessive hammer drag.
