Introduction
The Junghans 215 Westminster movement uses a classic quarter-chime system that plays progressively longer Westminster sequences at each quarter, followed by the hour strike on the hour. When the chime or strike sequence is out of order, the cause is usually cam alignment, rack-and-snail timing, or chime-train synchronization. This guide explains how the system is designed to function and how to diagnose common issues.
How the Junghans Westminster System Works
Quarter-chime progression
The movement plays 4 notes at the quarter hour, 8 notes at the half hour, 12 notes at the three-quarter hour, and the full 16-note Westminster melody on the hour.
Hour strike after the full chime
After the full Westminster melody, the strike train activates and counts the hour using the rack-and-snail system.
Chime cam control
A rotating cam determines which chime sequence plays at each quarter.
Chime train and strike train independence
Each train has its own power source and locking system but must remain synchronized.
Auto-correction feature
Many Junghans movements self-correct after one hour if the chime sequence is out of sync.
Understanding the Chime Sequence
Quarter hour (15 minutes)
Plays the first 4 notes of the Westminster melody.
Half hour (30 minutes)
Plays the first 8 notes.
Three-quarter hour (45 minutes)
Plays the first 12 notes.
Hour (60 minutes)
Plays the full 16-note melody, then activates the hour strike.
Strike count
The rack drops according to the snail position, striking the correct hour.
Diagnosing Sequence Problems
Chime plays wrong number of notes
Chime cam out of position or chime locking not resetting correctly.
Strike occurs before the full chime
Strike release lever misaligned or rack hook releasing too early.
Chime stalls mid-sequence
Power loss, worn pivots, or binding in the chime train.
Chime and strike out of sync
Movement may need to run through a full hour to self-correct.
Hour strike incorrect
Rack not dropping fully or snail misalignment.
Correcting Chime and Strike Issues
Step 1: Verify chime cam position
Ensure the cam aligns with the correct quarter sequence.
Step 2: Check chime locking
The chime train must lock cleanly at the end of each sequence.
Step 3: Inspect the rack and snail
Confirm the rack drops fully and the snail is aligned with the hour hand.
Step 4: Test the auto-correction
Allow the clock to run for one hour to see if the sequence resets.
Step 5: Check for power loss
Worn pivots, dirty arbors, or weak mainsprings can cause chime or strike failure.
Troubleshooting Flowcharts
If the chime plays the wrong sequence
Cam misaligned → Locking not resetting → Train binding → Auto-correction needed
If the strike fires early
Strike release lever too high → Rack hook slipping → Snail misaligned
If the chime stalls
Dirty pivots → Worn bushings → Weak mainspring → Hammer drag
If the hour strike is wrong
Rack not dropping → Snail rotated → Hour hand misaligned → Rack tail bent
If the chime is uneven
Hammer lift uneven → Rods misaligned → Train drag → Cam wear
Common Mistakes to Avoid
Forcing the hands backward
Can damage the chime cam and desynchronize the sequence.
Adjusting the rack without understanding the system
Incorrect adjustments cause hour-strike errors.
Oiling the chime rods or hammers
Oil deadens the sound and attracts dirt.
Skipping power checks
Weak power causes most chime and strike issues.
Testing outside the case only
Some issues appear only when the movement is installed.
Checklist for Final Verification
• Chime sequence correct
• Strike follows full chime
• Rack drops properly
• Snail aligned
• Hammers lift evenly
• Movement runs full hour cycle
FAQs
Why does my Junghans clock chime out of order?
The chime cam or locking system is out of sync.
Why does the strike occur before the chime finishes?
The strike release lever is misaligned.
How long does auto-correction take?
Usually one full hour cycle.
Why does the chime stall?
Power loss or binding in the chime train.
Is this a common Junghans issue?
Yes—cam alignment and chime locking drift over time.
