Introduction
Smiths Westminster clocks with the K7D floating-balance movement are known for smooth operation, but they are also sensitive to power loss, train binding, and chime-sequence issues. When a clock runs intermittently, stalls during the chime sequence, or behaves unpredictably, the cause is usually found in the power train, escape wheel, or floating balance assembly. This guide explains how to diagnose and correct the most common issues.
Understanding the Smiths Floating-Balance Movement
The floating balance
This balance assembly replaces a pendulum and is extremely sensitive to dirt, dried oil, and friction.
The escape wheel
The escape wheel must deliver consistent impulse. Any wear or dirt causes erratic running.
The chime train
Westminster chime sequences require smooth lifting of hammers. Excess lift or friction causes stalling.
The time train
Weak power in the time train often shows up as intermittent stopping or fluttering.
Importance of proper servicing
These movements require thorough cleaning, correct lubrication, and careful pivot inspection.
Common Problems Seen in This Movement
Clock runs briefly then stops
Usually caused by power loss, dirty pivots, or floating-balance friction.
Chimes stall or hesitate
Often due to excessive hammer lift or binding in the chime train.
Escape wheel fluttering
Indicates poor lock and drop or insufficient power.
Balance amplitude weak
Dirty balance pivots or dried oil in the balance cup reduce amplitude.
Clock runs on its back but not upright
Classic sign of pivot wear or depthing issues.
Diagnosing the Issue
Step 1: Mount the movement on a stand
A movement stand provides stability and visibility for inspecting the trains.
Step 2: Let down the mainsprings
Use a let down tool to safely release power before inspecting pivots or wheels.
Step 3: Inspect the escape wheel
Check for bent teeth, poor lock, or uneven drop. Fluttering indicates power loss.
Step 4: Check pivot wear
Oval holes or dark pivot rings indicate friction and power loss.
Step 5: Test the chime train by hand
Advance the train gently to feel for binding or excessive hammer lift.
Step 6: Examine the floating balance
Ensure the balance spins freely and the cup is clean and properly lubricated.
Correcting the Problem
Clean and lubricate the movement
Smiths floating-balance movements are extremely sensitive to dirt and dried oil.
Rebush worn pivot holes
Properly centered bushings restore power and depthing.
Polish pivots
Smooth pivots reduce friction and improve power delivery.
Adjust hammer lift
Reduce lift to the minimum needed for a clean chime.
Service the floating balance
Clean the balance cup, check the wire, and ensure free rotation.
Troubleshooting Flowcharts
If the clock stops randomly
Check pivots → Check escape wheel → Check balance → Check mainspring power
If the chime train stalls
Check hammer lift → Check drum → Check pivots → Check bushings
If the escape wheel flutters
Check lock → Check drop → Check pivot wear → Check power
If the balance amplitude is weak
Clean balance → Check cup → Check wire → Check power
If the clock runs only on its back
Pivot wear → Depthing issues → Power loss
Common Mistakes to Avoid
Oiling worn bushings
Oil cannot fix wear—bushings must be replaced.
Ignoring the floating balance
Even slight dirt or friction stops the movement.
Over-lifting the hammers
Too much lift stalls the chime train.
Skipping mainspring let-down
Unsafe and risks damaging the movement.
Testing without a movement stand
Harder to diagnose power and depthing issues.
Checklist for Final Verification
• Escape wheel running cleanly
• Floating balance spinning freely
• Pivots polished and clean
• Bushings properly centered
• Chime train lifts smoothly
• Movement runs reliably in upright position
FAQs
Why does my Smiths Westminster clock stop randomly?
Usually due to pivot wear, escape-wheel issues, or floating-balance friction.
Why does the chime stall?
Excessive hammer lift or binding in the chime train.
Why does the escape wheel flutter?
Indicates poor lock and drop or power loss.
Do I need a movement stand?
Yes—essential for diagnosing power and depthing issues.
Why use a let down tool?
To safely release mainspring power before servicing.
