Introduction
A broken gear in a Regula 25 cuckoo movement can stop the strike train, prevent the bird from emerging, or cause the bellows to lift unevenly. These movements are repairable, but proper diagnosis is essential before replacing any wheel. This guide explains how to identify the damaged gear, how the strike train interacts with the bird and bellows, and how to restore full operation.
How the Regula 25 Strike Train Works
Separate time and strike trains
The time train drives the pendulum and hands, while the strike train controls the call sequence.
Gear-driven lift system
The strike train lifts the bellows and pushes the bird outward through a series of levers and wires.
Warning and locking
The train enters warning before release, ensuring proper timing of the call.
Bird and door linkage
The bird moves in sync with the bellows lift and must travel freely.
Weight-driven power
The strike weight powers the entire call sequence; any gear damage interrupts it.
Diagnosing a Broken Gear
Check for missing or cracked teeth
Even a single missing tooth can stop the strike train or cause intermittent operation.
Inspect the pinion
Pinions often crack along the root, especially on older Regula wheels.
Test wheel freedom
Rotate each wheel gently—binding or sudden drops indicate damage.
Check lift timing
If the bellows lift unevenly or the bird hesitates, the damaged gear may be in the upper train.
Verify warning behavior
If the train fails to enter warning, the damaged wheel may be near the warning pin.
Replacing the Damaged Gear
Step 1: Identify the wheel
Determine whether the damaged gear is in the lower, mid, or upper strike train.
Step 2: Remove the movement
Take the movement out of the case to access the plates and wheels.
Step 3: Disassemble the plates
Let down power, remove the plates, and lift out the wheels carefully.
Step 4: Install the replacement wheel
Ensure the new wheel matches tooth count, pinion size, and arbor length.
Step 5: Reassemble and test
Verify smooth rotation and proper lift timing before reinstalling the movement.
Troubleshooting Flowcharts
If the strike won’t start
Broken tooth → Pinion crack → Warning not releasing → Lift wire binding
If the bird moves but no sound
Bellows leak → Lift too low → Bellows rubbing → Damaged gear slowing lift
If the call is weak or uneven
Upper-train damage → Lift wires misaligned → Bellows interference → Power loss
If the strike stalls mid-cycle
Gear damage → Dirty pivots → Worn bushings → Weight too light
If the bird sticks in the door
Door hinge friction → Linkage bent → Lift timing off → Gear slipping
Common Mistakes to Avoid
Replacing the wrong wheel
Always confirm the exact damaged gear before ordering parts.
Forcing the plates together
Guide each pivot carefully—forcing causes bent arbors.
Ignoring lift-wire alignment
Even with a new gear, misaligned lift wires cause weak calls.
Oiling the bellows
Never oil bellows or lift wires—oil attracts dirt and causes drag.
Testing outside the case only
Some issues appear only when the movement is installed.
Checklist for Final Verification
• New gear installed correctly
• Strike train runs freely
• Bellows lift evenly
• Bird travels smoothly
• Warning and release correct
• Movement runs full strike cycle
FAQs
Why does a broken gear stop the strike?
The strike train relies on uninterrupted power flow; one damaged tooth breaks the sequence.
Can Regula gears be repaired?
Minor cracks can sometimes be stabilized, but replacement is usually best.
Why does the bird hesitate?
Gear damage reduces lift power and disrupts timing.
Do I need to replace both bellows?
Only if they leak or lift unevenly—gear damage alone doesn’t require new bellows.
Is this a common Regula 25 issue?
Yes—older plastic pinions and wheels often crack with age.
